1080Kn Thrust Angular Contact Ball Bearing ZKLDF150 Spherical Roller Bearing

  • 1080Kn Thrust Angular Contact Ball Bearing ZKLDF150 Spherical Roller Bearing
Place of Origin China
Brand Name ZYS
Certification ISO9001, ISO14001, OHSAS18001
Model Number ZKLDF150
Minimum Order Quantity One set
Price USD 1 for one set
Packaging Details Standard package for export
Delivery Time 15-20 days
Supply Ability 20000 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model NO. ZKLDF150 Type No Gear
Application 1 Machine Tool Turntable Application 2 Grinding Head
Application 3 Testing Device Dimension Range 50-1030mm
Limiting Speed 440-35r/Min Dynamic Rated Load 38-1080kn
Static Rated Load 265-1860kn Transport Package Cases And Pallets Or As Customer′s Requirment
Specification Customized Trademark CAEC
Origin Luoyang, Henan, China HS Code 8482102000
Supply Ability 200/Month Standard Or Nonstandard Standard
Feature High Speed, Corrosion-Resistant, Heat-Resistant Sealing Gland Non-Seal
Rolling-Element Number Single-Row Roller Type Spherical Raceway
Material Bearing Steel Customization Available | Customized Request
High Light

1080Kn Thrust Angular Contact Ball Bearing

,

ZKLDF150 Spherical Roller Bearing

,

Thrust Angular Contact Ball Bearing ZKLDF150
Leave a Message
Product Description

ZKLDF thrust angular contact ball bearing



►Product description of ZKLDF bearing:

Thrust angular contact ball bearing ZKLDF series includes an integral outer ring, two inner rings and two sets of steel balls and cage assemblies, with a contact angle of 60°. Compared with ordinary bearings, ZKLDF series bearing can withstand higher axial and radial loads, and has higher tilt stiffness, low friction coefficient, high rotation accuracy, high limit speed, etc. Therefore, ZKLDF thrust angular contact ball bearings are particularly suitable for high-precision areas that require high speed, axial and radial loads, and overturning moments, and have long operating cycles, such as high-speed rotary tables, high-precision turntables, medical equipment, and high-precision testing device.



CAEC can offer YRT series, YRTS series, ZKLDF series, YRTM series, YRTSM series rotary table bearings. About the performance comparison of YRT, YRTS and ZKLDF series bearings with the same size, the limit speed of ZKLDF, YRTS, YRT series bearings decrease in turn while the overturning rigidity of YRTS, YRT and ZKLDF series bearings decrease sequentially. YRTM or YRTSM rotary table bearings add a set of angular displacement monitoring system on the basis of YRT or YRTS series bearings, to overcome the defect of open-loop control of diagonal displacement control, and realize closed-loop control of rotary table or indexing plate, greatly improving the positioning accuracy of angular displacement.


►Product structure of Slewing Ring Bearing:
Thrust / radial cylindrical roller bearings YRT and YRTS series are composed of two thrust roller bearings and one radial cylindrical roller bearing. Due to the special design of the internal structure of YRTS series bearing, higher limit speed can be achieved. Thrust angular contact ball bearings ZKLDF series consist of an integral outer ring, two inner rings and two sets of steel balls and cage assemblies. Its contact angle is 60, and it is especially for the conditions with high requirements on high speed, high axial and radial loads and overturning moment.

►Product Features of Rotary Table Bearing:
Turntable bearings are ready-to-install high-precision turntable bearings, suitable for occasions with high precision requirements and combined load. They can withstand radial loads, bidirectional axial loads and overturning moments with negative clearance. Turntable bearings have the characteristics of high precision, high rigidity and high load capacity. In order to facilitate transportation and installation, screw holes are opened on the inner ring and the outer ring, and the entire set of bearings is fastened with positioning screws. The bearings are preloaded at the factory, and there is no need to adjust the clearance for installation.



►Technical parameters of ZKLDF series rotary table bearing:

Bearing model Outer dimension (mm) Basic rated load (KN) Friction torque Limit speed Weight
d D H H1 d3 d1 d2 dn dm Ca Cor Nm R/min Kg
ZKLDF100 100 185 38 25 161 136 158 112 170 71 265 1.6 2800 4.5
ZKLDF120 120 410 40 26 185 159 181 135 195 76 315 2 2400 6
ZKLDF150 150 240 40 26 214 188 211 165 225 81 380 3 2000 7.5
ZKLDF200 200 300 45 30 274 243 271 215 285 121 610 4.5 1600 11
ZKLDF260 260 385 55 36.5 345 313 348 280 365 162 920 7.5 1200 22
ZKLDF325 325 450 60 40 415 380 413 342 430 172 1110 11 1000 28
ZKLDF395 395 525 65 42.5 486 450 488 415 505 241 1580 16 800 39
ZKLDF460 460 600 70 46 560 520 563 482 580 255 1860 21 700 50


►CEAC manufacturing capacity of cross roller bearings:



Made in China Slewing Ring Bearing Yrt Rotary Table Bearing Yrt260 Used for Machine Tool TurntableMade in China Slewing Ring Bearing Yrt Rotary Table Bearing Yrt260 Used for Machine Tool Turntable



►Application of rotary table bearings:



Made in China Slewing Ring Bearing Yrt Rotary Table Bearing Yrt260 Used for Machine Tool Turntable



►Package of YRT series bearing:

Made in China Slewing Ring Bearing Yrt Rotary Table Bearing Yrt260 Used for Machine Tool Turntable

FAQ

Q: Are you trading company or manufacturer?
A: CAEC is bearing manufacturer, the only first-class comprehensive research institute in China bearing industry.

Q: How do you control quality of bearing?
A: CAEC has established quality control systems for each kind of bearing and spindle. All products and services passed ISO9001-2008 Quality Certificate.

Q: What is the MOQ?
A: It depends on the bearing type. You can send inquiry or send e-mail for more information.

Q: How about the package?
A: Industrial packing in general condition (Plastic tube+ carton+ pallet). Accept design package when OEM.

Q: How long is the delivery time?
A: It will take about 10 to 40 days, depends on the model and quantity.

Q: How about the shipping?
A: We can arrange the shipment or you may have the forwarder.

Q: Is sample avaiable?
A: Yes, sample order is acceptable.

Q: Can we use our own LOGO or design on bearings?
A: Yes. OEM is acceptable. We can design the bearing with your requirements and use your own LOGO and package design.
